RRP D40x and AF-S18-55mm DX lens: £599.99
Sales start date: 29th March 2007
Nikon is pleased to announce the D40x, a Digital SLR camera that embodies a wide range of innovative features in a compact, stylish design.
The new model boasts a 10.2 megapixel CCD image sensor that combines with Nikon’s exclusive 3D Colour Matrix Metering II and auto white balance to produce quality shots that capture the vivid detail and true colour of the subject matter. The D40x is equipped with the compact, lightweight 3x 18-55mm f/3.5-5.6G ED II AF-S DX Zoom-Nikkor lens to provide superb picture sharpness and optimum contrast. The new D40x is also compatible with the 55-200mm VR Zoom-Nikkor telephoto and is ideal for extending the focal range as the user develops their photography skills. The new lens is fitted with an ED glass element, making it easier to achieve images with higher resolution and high contrast. The Silent Wave Motor offers quiet and smooth auto focusing.
The Nikon D40x has a near instant power-up and a continuous shooting mode which allows the keen photographer to capture 100 jpeg images at three frames per second. The integrated auto focus ensures that shots are crisp and clear and Nikon’s innovative i-TTL flash control evaluates ideal flash exposure to ensure the image light is always correct, whatever the conditions. An additional ISO 100 setting extends the ISO range over the D40 giving photographers the flexibility to shoot in a variety of conditions at ease.
An ample 2.5-inch LCD screen means the budding photographer can view, manipulate and navigate their images with ease. Unique Nikon innovations make it possible to manipulate the images in-camera, allowing amateurs to achieve professional results. Nikon’s unique D-Lighting function improves areas of underexposure in images taken with too much back light by creating a copy of an image with added light and detail wherever necessary, leaving well-exposed areas untouched. Photographers are also able to fix red eye at the touch of a button or use the monochrome effect to produce a black and white image. Nikon’s exclusive PictureProject software makes it easy to edit, organise, transfer and share the high quality images. The camera comes complete with a longer-life battery.
For the creative photographer, Nikon’s user friendly scene-optimised Digital Vari-program modes helps the user to capture any scene with ease. The eight modes are designed to produce remarkable results by automatically calculating the best settings and ISO equivalent sensitivity for each scene.
D40X Major Features Intuitive, simple and trouble-free operation
• The most compact Nikon digital SLR ever, featuring intuitive controls and ergonomics designed for everyone
• A large 2.5-inch LCD monitor with easy-to-view menus, large fonts and careful colour schemes for easy preview and setting changes
• Bright and clear viewfinder with 0.8x magnification for precise composition
• Long-life rechargeable lithium-ion battery that allows up to 520 images* on a single charge (*CIPA standards)
• Handy images assist that helps photographers select the right camera settings
• Optional Wireless Remote Control ML-L3 for easy remote shutter release
Superior image quality and resolution
• 10.2-effective-megapixel Nikon DX Format CCD imaging sensor, producing 3,872 x 2,592-pixel images
• High-precision digital image processing algorithms for natural-looking pictures with faithful colour and tone reproduction
• Nikon 3D Colour Matrix Metering II for ideal exposures in almost any lighting condition
• Variable Centre-weighted metering and Spot metering centered on the active focus area
• Auto White Balance for natural colours, plus six different manual white balance settings and user-defined preset white balance
Fast and precise responses
• Quick 0.18-sec. power-up to respond to every photographic opportunity
• Fast continuous shooting mode enables up to 100 JPEG images (FINE L-size or smaller) at 3 frames* per second
• *The fastest frame rates can be achieved by choosing manual focus, rotating the mode dial to S or M and selecting a shutter speed of 1/250 s. or faster, using defaults for all other settings.
• Advanced three-area AF system and refined algorithms for fast, efficient and precise autofocus
• Versatile shutter speed control ranging from 30s to 1/4000s, plus bulb
Accurate automated and manual control for predictable results
• Eight Digital Vari-Programs that adjust camera settings automatically for incredible scene-specific pictures. Selections include Auto, Auto (Flash Off), Portrait, Landscape, Child, Sports, Close Up, and Night Portrait
• Manual controls over shutter and aperture: P (Programmed Auto), S (Shutter-priority Auto), A (Aperture-priority Auto) and M (Manual)
• Automatic and manual control over ISO sensitivity from ISO 100 to 1600, as well as HI 1 (manual selection only) giving the equivalent of ISO 3200
• Simultaneous recording of NEF (RAW) and JPEG basic data for the same image
• Built-in Flash with Nikon’s dependable i-TTL flash control, supporting Auto flash, Red-eye reduction, Slow sync, Rear curtain sync and Flash exposure compensation
Retouch Menu for creative in-camera image edits and effects
• Selections include D-lighting, Red-eye correction, Trim, Monochrome (Black-and-white, Sepia, Cyanotype), Filter effects (Skylight, Warm filter, Colour balance), Small picture and Image overlay
Seamless integration with Nikon Total Digital Imaging System
• Fully compatible (autofocus is supported) with AF-S and AF-I Nikkor lenses, which are equipped with an autofocus motor (Also compatible with most of the world-famous F-mount Nikkor lenses when in manual focus mode)
• Supports the Nikon Creative Lighting System when using the SB-800, SB-600, SB-400, SB-R200 or the R1C1 Wireless Close-Up Speedlight system for accurate exposures via iTTL flash and versatile wireless operation
• Nikon’s PictureProject software to share, organize and edit pictures with ease.
• Capture NX software (available separately) for creative photo editing with NEF (RAW), JPEG and TIFF images. Thanks to U Point™ technology, by Nik Software, radical and subtle image enhancements are as easy as a few clicks
Auto (TTL white-balance with 420-pixel RGB sensor), six manual modes with fine-tuning and preset white balance
LCD Monitor
2.5-in., 230,000-dot, low-temperature polysilicon TFT LCD with brightness adjustment
Playback Function
1 frame; Thumbnail (4 or 9 segments); Magnifying playback; Slide show; Histogram indication; Highlight point display; Auto image rotation
Delete Function
Card format, All frames delete, Selected frames delete
Video Output
NTSC or PAL
Interface
High-speed USB: Mass Storage and MTP/PTP selectable
Text Input
Up to 36 characters of alphanumeric text input available with LCD monitor and multi selector; stored in Exif header
Compatible Lenses*1
Nikon F mount with AF coupling and AF contacts Type G or D AF Nikkor
1) AF-S, AF-I: All functions supported, 2) Other Type G or D AF Nikkor: All functions supported except autofocus, 3) PC Micro-Nikkor 85mm f/2.8D: Can only be used in mode M; all other functions supported except autofocus, 4) Other AF Nikkor*2/AI-P Nikkor: All functions supported except autofocus and 3D Colour Matrix Metering II, 5): Non-CPU: Can be used in mode M, but exposure meter does not function; electronic rangefinder can be used if maximum aperture is f/5.6 or faster *1. IX Nikkor lenses can not be used *2. Excluding lenses for F3AF
Picture Angle
Equivalent in 35mm [135] format is approx. 1.5 times lens focal length
Viewfinder
Fixed-eyelevel penta-Dach mirror type; built-in diopter adjustment (-1.7 to +0.5m-1)
Eyepoint
18mm (-1.0 m-1)
Focusing Screen
Type B BriteView Clear Matte screen Mark V with superimposed focus brackets
TTL phase detection by Nikon Multi-CAM530 autofocus sensor module with AF-assist illuminator (range approximately 0.5-3.0m/1ft. 8in.-9ft. 10in.); Detection range: -1 to +19 EV (ISO 100 at 20°C/68°F)
Lens Servo
1) Autofocus (AF): Instant single-servo AF (AF-S); continuous servo AF (AF-C); auto AF-S/AF-C selection (AF-A); predictive focus tracking automatically activated according to subject status, 2) Manual focus (M)
Focus Area
Can be selected from three focus areas
AF Area Modes
1) Single Area AF, 2) Dynamic Area AF, 3) Dynamic Area AF with Closest Subject Priority
Focus Lock
Focus can be locked by pressing shutter-release button halfway (single-servo AF) or by pressing AE-L/AF-L button
Exposure Metering
System
TTL exposure metering system
1) 3D Colour Matrix Metering II (type G and D lenses); Colour Matrix Metering II (other CPU lenses); metering performed by 420-pixel RGB sensor
2) Center-weighted: Weight of 75% given to 8mm circle in centre of frame
3) Spot: Meters 3.5mm circle (about 2.5% of frame) centered on active focus area
Exposure Metering Range
1) 0 to 20 EV (3D Colour Matrix or center-weighted metering), 2) 2 to 20 EV (spot metering)
Exposure Modes
Digital Vari-program (Auto, Auto [Flash Off], Portrait, Landscape, Child, Sports, Close Up, Night Portrait), Programmed Auto (P) with flexible program; Shutter-Priority Auto (S); Aperture Priority Auto (A); Manual (M)
Exposure Compensation
±5 EV in increments of 1/3 EV
Exposure Lock
Exposure locked at detected value with AE-L/AF-L button
Shooting Modes
1) Single frame shooting mode, 2) Continuous shooting mode: approx. 3 frames per second*, 3) Self-timer mode, 4) Delayed remote mode: 2 s. delay, 5) Quick-response remote mode
*The fastest frame rates can be achieved by choosing manual focus, rotating the mode dial to S or M and selecting a shutter speed of 1/250 s. or faster, using defaults for all other settings.
Shutter
Electronically controlled vertical-travel focal plane shutter, 30 to 1/4000 s. in steps of 1/3 EV, bulb
Sync Contact
X-contact only; flash synchronization at up to 1/200 s.
Flash Control
1) TTL: TTL flash control by 420-pixel RGB sensor. i-TTL balanced fill-flash for digital SLR and standard i-TTL fill-flash for digital SLR available when CPU lens is used with built-in flash, SB-800, SB-600, and SB-400, 2) Auto aperture: Available with SB-800 with CPU lens, 3) Non-TTL Auto: Available with Speedlights such as SB-800, 80DX, 28DX, 28, 27, and 22s , 4) Range-priority manual: Available with SB-800
Flash Sync Modes
AUTO, Portrait, Child, Close Up: Auto, auto with red-eye reduction; fill-flash and red-eye reduction available with optional Speedlight
Night portrait: Auto, auto slow sync, auto slow sync with red-eye reduction; slow sync and slow sync with red-eye reduction available with optional Speedlight
Landscape, Sport: Fill-flash and red-eye reduction available with optional Speedlight
P, A: Fill-flash, rear-curtain with slow sync, slow sync, slow sync with red-eye reduction, red-eye reduction
S, M: Fill-flash, rear-curtain sync, red-eye reduction
Built-in Flash
AUTO, Portrait, Child, Close Up, Night Portrait: Auto flash with auto pop-up
P/S/A/M: Manual pop-up with button release
Guide number (ISO 100, m /ft.): approx. 12/39 (manual full 13/42)
Flash Compensation
-3 to +1 EV in increments of 1/3 EV
Accessory Shoe
Standard ISO hot-shoe contact with sync, signal, and ground contacts and safety lock
Self-timer
Electronically controlled timer with duration of 2, 5, 10 or 20 s.
Remote Control
Via Wireless Remote Control ML-L3 (optional)
Power Source
One Rechargeable Li-ion Battery EN-EL9; charging voltage (Quick Charger MH-23): 7.4V DC, AC Adapter EH-5 (available separately; requires optional AC Adapter Connector EP-5)
Tripod Socket
1/4 in. (ISO1222)
Dimensions (W x D x H)
Approx. 126 x 64 x 94mm (5.0 x 2.5 x 3.7 in.)
Weight
Approx. 495g (1lb. 1oz.) without battery, memory card or body cap
Supplied Accessories*
Rechargeable Li-ion Battery EN-EL9, Quick Charger MH-23, USB Cable UC-E4, PictureProject, Rubber Eyecup DK-16, Camera Strap, Body Cap BF-1A, Eyepiece Cap DK-5, Accessory Shoe Cap BS-1
Optional Accessories
Wireless Remote Control ML-L3, Capture NX, Camera Control Pro, AC Adapter Connector EP-5, AC Adapter EH-5, Video Cable EG-D100, Semi Soft-Case CF-DC1, Speedlight SB-800, SB-600, SB-400 and R1C1
